30W -100W Wood Laser Marking Machine | CO2 Galvo Laser Marker

Our desktop wood laser marking machine is equipped with pulleys that can be moved between different work locations. Drawers provide additional storage space to store tools, accessories, and materials, keeping the work area tidy.

The CO2 Galvo laser marker supports a power of 30W, 50W,60W， and 100W, with a marking range of 110mm-300mm. It is equipped with a high-quality imported galvanometer system to achieve high-precision and high-efficiency marking.

Send Inquiry
Chat Now
Facebook
Model PB30 PB50 PB60 PB100
Supply Voltage 110V/220V, 50/60Hz 110V/220V, 50/60Hz 110V/220V, 50/60Hz 110V/220V, 50/60Hz
Total Power Consumption 900W 900W 1500W 1500W
Cooling Method Air Cooling Air Cooling Air Cooling Water Cooling
Machine Dimensions 600*775*1430 mm 600*775*1430 mm 600*775*1430 mm 600*775*1430 mm
Machine Weight Approx. 70 kg Approx. 70 kg Approx. 80 kg Approx. 85 kg
Optical Parameters
Output Power 30W 50W 60W 100W
Galvo Scanner RC 1001 RC 1001 RC 1001 RC 1001
Laser Source DAVI / YL / CRD DAVI / YL / CRD DAVI / YL / CRD DAVI / YL / CRD
Adjustable Frequency Range 1-100kHz 1-100kHz 1-100kHz 1-100kHz
Laser Wavelength 10600 nm 10600 nm 10600 nm 10600 nm
Beam Diameter 2±0.2mm 2±0.2mm 2±0.2mm 2±0.2mm
Marking Area 100*100 mm – 180*180 mm 100*100 mm – 300*300 mm 100*100 mm – 300*300 mm 100*100 mm – 300*300 mm
Power Adjustment Range (%) 0-100% 0-100% 0-100% 0-100%
Cable Length 3m 3m 3m 3m
System Software EZCAD2 EZCAD2 EZCAD2 EZCAD2
